Why the LPG Cylinders are exploding, during fire?

Have you ever had a doubt, why the LPG cylinders are exploding, during fire?



The Explosion, (the sudden release of blast wave) is one of the major reasons for the damage to buildings and injury to occupants during LPG leaks.

If the cylinder is not exploded during fire, most of the building damage and risk to neighborhood’s can be minimized.

Let’s come to the answer,

  • If the LPG Cylinder is subjected either to fire or any other heat source, the liquefied petroleum will change in to gaseous state. (As temperature increases the liquids will convert to gaseous stage )
  • If it is continuously subjects to heat, than the contents of LPG will restore to gaseous stage, which increases the internal pressure inside the Cylinder.
  • Though the Liquid space of the cylinder absorbs the heat and sinks, but in the gaseous space (the space above the liquid space) will not have any medium to reduce the heat, so most of the energy will be absorbed by the Cylinder.
  • If the cylinder subjected to heat, it will starts to melt and on a certain stage it will fail, in which the sudden release of pressurized gas space comes out as an explosion.

What to do when LPG Smell found in Home?

LPG Cylinders are most hazardous, which can kill the entire occupant’s in home.
Do you believe, all you family members, knew the action to take, when the LPG smell founds in kitchens or home.



Absolutely, the answer will be “No”

Imagine, if your mom or sister or any of your family member are not aware the actions to take in case of LPG Leaks, what will happen, even it cannot be imagined.

So here we are talking about the serious issue, which is worthy to read further,


If you have a doubt that the LPG may leak from cylinders, follow this 7 proven and tried steps to keep yourself safe.

  1. Turn off the regulator & valve both in LPG cylinder & stove
  2. Do not turn on or turn off any switches such as lights or fan (the minor spark produced from the switches can act as an ignition source and may leads to explosion)
  3. Open all your windows & doors to allow the LPG gas too dilute
  4. Get all your family member’s outside the home
  5. Do not try to seal or repair the leaks from yourself, hence you are not person trained in it.
  6.  Call to the supplier or agent, from whom you purchased the LPG cylinders.
  7. Inform the situation & wait until they arrive and repair.


“Contribute to public safety; by Sharing your Experience with LPG Cylinders & fire incidents in comments”

Truck Safety Checklist


  1. Whether Protection FOPS  (canopies, screens) is provided to shield operator from falling objects?
  2. Whether horn and reverse alarm are available and in working condition?
  3. Do the Hydraulic system in working condition during unloading of materials?
  4. Whether moving parts, shafts, sprockets, belts, etc. are guarded.
  5. Whether Protection against contact with hot surfaces, exhaust, and etc.is provided.
  6. Safe means of access (steps, grab bars, non-slip surfaces) to the cab is provided
  7. Whether Damage in tire
  8. Do the tires are checked for (Crack, cut, & air has been checked &
  9. Do the Tyre pressure is within the safe limit?
  10. Whether Leakage of oil from the vehicle parts and vehicle oil tank has been checked ?
  11. Do the Vehicle rear view mirror is available?
  12. Whether Head light, Tail lamp are fitted & in working condition (for night work)
  13. Whether Brake, accelerator, clutch are in working condition?
  14. Whether lock of the back door (trailer) in working condition and Safe?
  15. Whether Inter locking system between the tractor and the trailer working condition?
  16. Whether Visualization of Check sheet and Operator details with photo is available in the vehicle?
  17. Do the  Vehicle having valid insurance paper?




Scissor Lift safety Checklist





  • Do the SWL marked on bucket ?
  • Do the Platform safety door in good condition?
  • Whether the Toe guard provided to scissor lift platform?
  • Whether Tyre conditions are safe & there is no Damage in Tyre (Crack, Cut, etc.)
  • Whether Emergency switch is in working condition?
  • Whether Emergency rescue system is in working condition. (When Engine fails)
  • No oil leak (Hydraulic parts, Engine and fuel tank)
  • Machine Marching alarm in working condition
  • Scissor structure condition while full expansion (Damage, crack and jamming while extending)
  • Fire Extinguisher availability
  • All limit switch is in working condition) over loading, over reaching)
  • Ensure break system is in working condition
  • Operator details displayed on scissor lift
  • Emergency contact numbers displayed
  • Ensure operator having valid license
  • Done and due date of third party certification mentioned on scissor lift
  • Warning Lamp is in working condition
  • Display the instruction of operating
  • Required PPE'S displayed on bucket

Safety Career objectives for freshers




  • To use the Knowledge I learned during my Industrial safety diploma and to apply the safety strategies I learned to enhance the company health and safety performance.
  • To reach the zero accidents and ill-health in the organization by applying the legal standards and risk control strategies I learned during my curriculum
  • To reach the managerial position in health and safety department, and assisting the organization to reach the ultimate health and safety Goals.
  • To be an part of health and safety management and to devise the innovative ideas in health and safety to meet the ultimate goals
  • To support the organization to meet both legal and organizational goals related to health and Safety.
  • A dedicated and proactive health and safety student searching for a health and safety officer jobs, to enhance both myself and the organization OHS Performance.
  • To work in the company, where I can utilize the knowledge and skills learned during my health and safety qualifications and to achieve the zero accidents in the company I work for.

What is the scope of Industrial Safety Diploma & Engineers?


What is the scope of Industrial Safety Diploma & Engineers?

“What is the Scope of industrial safety diploma”


The common questions among the students wish to take industrial safety engineering courses,



Workplaces are becoming unsafe; due to the number of factors such us,


The use of large machinery,
The use of hazardous chemicals,
The use of high voltage electricity,
The presence of excessive noise, vibration, heat etc,


The ILO Declared


“Every 15 Seconds a worker met an accident in his workplace”



Hope now, you can understand “How hazardous the industries are”


It’s not easier to perform the entire industrial activities safely, without separate mechanisms and manpower to control it.


Also, we cannot perform the Industrial activities without using machines, chemicals, electricity etc.


So the Industries need a competent Industrial safety engineers who knows “the casual factors of accidents and the methods to control it”


Also In every countries the Companies having a legal requirement to appoint competent

“Industrial safety engineers”


If the company fails to appoint competent industrial safety engineers to manage their risks, the companies may incur enforcement notices, criminal fines from the government authorities.

And now the awareness among the industries are grows up and the trade unions and insurance companies are insisting health and safety in the workplace.


Finally,


As technology and science increases, the probability of accidents and occupational ill-health also increases.

So the Industrial safety engineers will find a huge demand in the market in upcoming years.
















Contractors safety Audit Checklist




  1. Is the Company Safety Policy displayed at the identified areas?
  2. Is full time site safety officer deputed at site?
  3. Is Site Safety Officer approved by EHS department?
  4. Are construction safety manual & safety procedure manual available at site?
  5. Does the site have safety committee?
  6. Are sub-contractors included in safety committee?
  7. Is safety committee meeting held monthly?
  8. Are unsafe acts /conditions, accident causes and recommendations discussed in meeting?
  9. Are action by and target date columns included in minutes of meetings?
  10. Are minutes of meeting circulated among members and copy sent to EHS Department?
  11. Is accident reporting and Investigation procedure followed at site?
  12. Are near miss accidents reported and investigated?
  13. Is safety day / week celebrated at site?
  14. Are safety posters displayed at site?
  15. Are adequate numbers of first aid boxes available at site?
  16. Is ambulance available at site?
  17. Is clinic available at site?
  18. Is housekeeping in order?
  19. Are walkways clear from obstruction?
  20. Is material stacked properly?
  21. Are sufficient dustbins provided?
  22. Is work permit system followed at site?
  23. Weather all safety precautions taken, which are mentioned in work permit?
  24. Are Personal Protective Equipment (PPE) provided for employees?
  25. Are employees using PPE?
  26. Are safety belts used for working at height above 2 Meters?
  27. Are safety belts anchored to fixed point?
  28. Are ear muffs / plugs provided, where noise level is more than 85 dB?
  29. Is safe access / platform provided for working at height?
  30. Are adequate scaffolding provided for working at height?
  31. Is scaffolding checked / inspected before use?
  32. Are sufficient fire extinguishers properly serviced and validity date marked on it?
  33. Are fire extinguishers properly serviced and validity date marked on it?
  34. Are employees trained for operating fire extinguishers?
  35. Weather all lifting equipment / tackles are marked with their S.W.L.?
  36. Are inspection / test certificates of competent person (s) available at site?
  37. Are adequate lifting tackles provided at site?
  38. Are trained operators engaged for operating the equipment?
  39. Are lifting / tackles maintained in good working conditions and record maintained?
  40. Weather proper storage is provided for gas cylinders?
  41. Weather valve protection caps are provided for gas cylinders?
  42. Weather flash back arresters provided for oxy-acetylene gas cutting set?
  43. Weather trolley provided for gas cutting set?
  44. Weather proper clamps provided for hose connection?
  45. Are pressure vessels tested / certified by competent person?
  46. Is emergency vehicle available at site?
  47. Are guards of machinery's in position?
  48. Is work place properly illuminated?
  49. Are adequate ladders provided at site?
  50. Is monthly accident statistics report copy sent to EHS?
  51. Are accident prevention tools & safety-related items available at site as per procedure?
  52. Is safety performance board displayed at site?
  53. Are excavations safe for work?
  54. Are excavations barricaded?
  55. Is proper slope or shoring provided for excavations?
  56. Weather Construction Equipment, hand tools are in good working condition?
  57. Are damaged equipment/ tools discarded?
  58. Weather portable electrical Equipment/ tools are in good working condition?
  59. Are access ladders checked and certified.
  60. Is there system in place for certification of scaffoldings?
  61. Is earthling provided for portable grinding machines?
  62. Are guards provided for portable grinding machines?

Portable Grinding machine safety Checklist



  • Whether fiber handle without damage & condition is ok.
  • Whether Wheel guard available & (covering 3/4th area).
  • Whether Grinding wheel having any crack/ damage. And Grinding wheels’ expiry date & its RPM match with the machine RPM” has been checked.
  • Whether Rear handle is having any damage.
  • whether Presence of Cord strain reliever (glands).are available & ok
  • Whether Trigger switch is having any damage.
  • Whether Presence of Switch lock is ok.  And in working condition.
  • Whether Electric wire having any cuts and joints.
  • Double earthling has been provided in m/c to avoid shock.



Main electrical panel board safety checklist



  1. whether Firm Base with grouting & Easily accessible panel (height of the leg is equal to 1m)
  2. whether D.B .set is weather proof and cover all around To avoid water/ dust
  3. Whether Authorized Operator/Elec. Name/ Photo/ Contact No.on DB panel are avail.
  4. Whether Visualization of voltage, current and type of tools to be used in the socket & Panel.
  5. Whether Confirmation of LOTO (lock out/ tag out) are available.
  6. WHETHER Safety stickers/ signboards / isolate flammable Fire Hazard are display in D.B,
  7. WHETHER Double Earthling System of MDB / DB panel with Std earthling pit has been provided.
  8. Whether Separate ELCB with tripping current of 30 mA & in working condition.
  9. whether Hilum sheet to be provided over live bus bars
  10. Whether Condition of Cable, Power Socket and Plug are having any damage.
  11. whether Color coding being followed (RYBWG) for all cables/wires
  12. whether Plug/ Socket are being used of Industrial type
  13. Whether availability of rubber mat in front of the D.B .

Hydraulic Mobile Crane Safety Checklist

Hydraulic Mobile Crane Safety Checklist


  1. Whether Safety latch in hook, available & in working condition.
  2. whether Hoist limit switch (Or presence of plate).available& working
  3. whether SWL mark in crane are visible
  4. Whether Wire rope and slings free from tolerable damage (No kinks, broken wires more than 10% is N.G).
  5. whether oil leak in hydraulic parts (piston drums) has been checked & ok
  6. whether Damage in Tire ( Crack, cut, has been checked & tire pressure ok
  7. Whether Head and tail lamps are available (for night working).
  8. Whether Front and reverse horn fitted & in working condition.
  9. Whether Boom structure condition while full expansion (damage, crack and jamming while extending).
  10. Whether Fire extinguisher is available in operator cabin.
  11. Whether valid Third party certificate (Form 32) are available.
  12. Whether Operator have licensed (heavy duty).
  13. whether Vehicle have valid insurance paper
  14. Whether Road tax document are available.

Gas cutting Equipment safety Checklist



  • whether Protective valve cap firmly fixed for both cylinder(Check for damage/crack in the valve cap)
  • whether Pressure gauges two for each cylinder(in & out)are in working condition(both Oxygen & Acetylene gas)
  • whether Flash back arrestor (FBAs)has been provided for  acetylene & oxygen cylinders
  • Whether Non return valves (NRVs) is provided for both acetylene & oxygen cylinders hose fitted with cutting torch to avoid back fire.
  • Whether Tight crimping of hoses with jubilee clamps are fitted.
  • Whether Hose free from damage (cut and crack / oil & grease to avoid leakage/ fire.
  • Whether Cylinder secured by chain to the trolley.
  • Whether Trolley tire are free from damage and in working condition.
  • Availability of industrial type lighter (no match box / commercial lighters) are allowed.
  • whether gas leak test has been done before starting the job to avoid fire.

Excavator Safety checklist



  • Front & reverse horn available & in working condition?
  • Whether Head & tail lamps (for working at night)?
  • Whether Leakage of oil (in hydraulic & pneumatic systems has been checked)?
  • Whether Loose bolts /connecting pins (In bucket, dosser and all links) has been checked?
  • Whether Back view mirror is available & condition is ok.
  • Roller-crawler / tire condition (check for damaged / missing idle rollers)
  • whether Structure been condition(damage, cut, crack) has been checked and ok
  • Diesel, oil and grease spillage.
  • Whether Fire extinguisher in operator cabin is available.
  • whether swinging horn is available and in working condition
  • Whether Equipment having proper & valid documents
  • whether Crawler Excavator having Safe Access and Egress for Operator
  • Whether Operator having license and (heavy duty). With valid date.
  •

Date:


Inspected Person name & Signature:

Drilling Machine Safety Checklist



  • whether Fore handle is good & in operating condition
  • whether Double insulation provided for the equipment (written in the machine body)
  • whether Equipment are free from any defect like broken Handle, broken parts etc
  • whether Magnetic base is in charged condition
  • Whether Presence of Cord strains reliever (glands) are available.
  • whether Fuse is available & in good condition
  • Whether Presence of Drilling trigger switch lock in working condition.
  • Whether Electric wire having any cuts and joints.
  • Whether Drilling Bit in good condition.
  • Whether Condition of the presence On/off switch is ok.
  • Whether Presence of dust cleaning brush near the equipment is available.
  • ELCB & the presence of industrial plug/three pin plug available and has been checked.

Cutting Machine Safety Checklist




  • Whether cutting wheel having any crack/ damage. And cutting wheels’ expiry date & its RPM match with the machine RPM” has been checked.
  • Presence of Cutting plate guard. Double earthling has been provided in m/c to avoid shock.
  • Whether Presence of locking system for the plate & Guard is available
  • Whether Presence of job clamp and its condition is ok
  • Whether Presence of fiber body handle and its condition is ok
  • Whether Cable condition (Any cut, wear etc) and presence of wire top plug is ok
  • Whether Presence of cutting dust guard is available



Bar cutting Equipment safety Checklist

  • Guard provided for any rotating parts.
  • Hot surface is provided with guard.
  • Rubber mat is provided in operator standing area.( around the D.G)
  • No oil leakage from the oil tank & other parts of the m/c.
  • Proper access to the D.G control panel
  • Exhaust smoke pipe faced upwards & outside of D.G shelter
  • Adequate ventilation in case of indoor generator
  • Presence of fire extinguisher (ABC type)
  • Presence of damage free operating switch, Voltage and temperature meter, circuit breaker, Oil level indicator, Emergency switch
  • Earthling is provided with standard earthling pit.
  • Proper foundation done

Arc welding machine Checklist


  •         whether ON / OFF knob is provided (Check for damage and insulated knob
  •        whether Regulator with indicator is provided
  •         Whether Welding cables connected to the welding machine with lugs at the joints with proper insulation.
  •       whether any cuts/ damage in the insulation of welding cables
  •         Whether Electrode rod holder and earthen holder are having any cuts/ damage/ broken and properly insulated.
  •         Whether Industrial Type Plug / socket being used for power tapping cable of welding machine.
  •         whether any internal live electrical parts of welding machine are exposed
  •       Whether Trolley being used w/o damaged wheels.
  •          Double earthling has been provided to machine.
  •       Whether co2 Fire extinguisher and fire bucket with sand are available near m/c.
  •          whether double earthling has been provided to m/c
